Residual Current Transducer
Residual Current Transducer
HANGZHI residual current transducers are able to detect small current with high accuracy of 0.2% for 0.1~5A and 1.0% for 0.01~0.05A.
Description
Application Area
Product List
| Product Model |
Rated Input(A) |
Overload Capacity(A) |
Rated Output(mA/V) |
Working Power(V) |
Accuracy (ppm/%) |
Linearity (ppm/%) |
Bandwidth (kHz) |
Aperture (Φmm) |
Product Specifications |
|---|---|---|---|---|---|---|---|---|---|
| RIT5 | ±5 | ±10 | 5V | ±15 | 0.2% | 0.1% | 100 | 26 |  |
| RIT3 | ±3 | ±6 | 3V | ±15 | 0.2% | 0.1% | 100 | 26 |  |
| RIT2 | ±2 | ±4 | 2V | ±15 | 0.2% | 0.1% | 100 | 26 | |
| RIT1 | ±1 | ±2 | 2V | ±15 | 0.2% | 0.1% | 100 | 26 | |
| RIT05 | ±0.5 | ±1 | 2V | ±15 | 0.2% | 0.1% | 100 | 26 | |
| RIT01 | ±0.1 | ±0.2 | 2V | ±15 | 0.2% | 0.1% | 100 | 26 | |
| RIT005 | ±0.05 | ±0.1 | 1V | ±15 | 1.0% | 0.2% | 100 | 26 | |
| RIT002 | ±0.02 | ±0.04 | 1V | ±15 | 1.0% | 0.2% | 100 | 26 | |
| RIT001 | ±0.01 | ±0.02 | 1V | ±15 | 1.0% | 0.2% | 100 | 26 | |
